Powerful Copper Rod Continuous Casting / Brass Continuous Casting Machine

Wuxi Huadong Industrial Electrical Furnace Co.,Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Powerful Copper Rod Continuous Casting / Brass Continuous Casting Machine from wholesalers

    Buy cheap Powerful Copper Rod Continuous Casting / Brass Continuous Casting Machine from wholesalers
    • Buy cheap Powerful Copper Rod Continuous Casting / Brass Continuous Casting Machine from wholesalers
    • Buy cheap Powerful Copper Rod Continuous Casting / Brass Continuous Casting Machine from wholesalers
    • Buy cheap Powerful Copper Rod Continuous Casting / Brass Continuous Casting Machine from wholesalers

    Powerful Copper Rod Continuous Casting / Brass Continuous Casting Machine

    Ask Lasest Price
    Brand Name : Jingjie
    Model Number : HCCM
    Certification : CE/ISO
    Price : negotiation
    Payment Terms : T/T or L/C
    Supply Ability : 10sets per month
    Delivery Time : 30 working days after received your payment
    • Product Details
    • Company Profile

    Powerful Copper Rod Continuous Casting / Brass Continuous Casting Machine

    D250mm Copper Rod Continuous Casting / Brass Continuous Casting Machine

    Horizontal continuous casting machine is mainly used for brass/bronze bar,brass/bronze tube making.The materials can be pure brass/bronze ,scrap brass/bronze and other brass/bronze materials.


    Main composed parts :

    No

    Items

    Specific

    Q’ty

    Remarks

    1Split Type Furnace

    Melting Furnace


    210KW


    1SET

    3-phase Balance

    Brand of Electrical Components: CHNT, Including furnace lining materials, 1SET

    Electrical System of Melting Furnace


    1SET

    3-phase Balance

    Hydraulic Furnace-Tilting System


    1SET

    Main Components: Qualified, Made in China

    Chute

    1SET

    Holding Furnace


    120KW


    SET

    3-phase Balance

    Brand of Electrical Components: CHNT, Including furnace lining materials, 1SET

    Electrical System of Holding Furnace


    1SET


    3-phase Balance


    Automatic Control System of Temperature


    1SET


    Including Thermalcouples and Protection Tube of Thermalcouple


    Furnace Face-plate of Mould


    2PCS


    Ф(60~25)x(8~4.5)mm



    Refractory Bricks around Furnace Mouth


    2/PCS

    Silicon Carbide

    2

    Crystallzer

    One use one standy


    Ф(60-25)

    x(8-4.5)mm


    8SETS


    Including Graphite Dies(20sets) and Dummy Bar and Dummy Bar Head

    3

    Upholding Roller between Caster & Tractor


    1SET

    4

    PLC Servo Auto CCM

    Continuous casting machine


    1SET

    Made by the Manufacturer

    PLC Servo motor and Auto Control Cabinet


    1SET

    Servo-motor:4.4KW

    Yaskawa,Japan

    5

    Auto-tracking Cutting Machine


    1SET

    6

    Cutting System of Mold Replacement


    1SET

    7

    Pneumatic Tilting (Storage) Table


    1SET

    Effective Length:6Meters

    8

    Cooling Water Dispenser


    2SETS

    Warning Function of Water Pressure and Flow Rate


    FOR BRASS BARS AND TUBES

    Technical parameters for induction furnace:

    Model
    GYT-150
    GYT-200
    GYT-300
    GYT-500
    GYT-750
    Rated capacity(kg)
    500
    800
    1200
    1800
    2000
    Rated power(kw)
    45
    60
    90
    120
    180
    Melting rate(kg/h)
    150
    200
    300
    500
    750
    Rated temperature(oC)
    1250
    Power consumption (KW·h/t)
    320
    300
    280
    260
    260
    Phase
    3-phase
    Voltage
    220v,380v,400v,415v,440v,460v etc,.
    Frequency
    50hz/60hz

    Powerful Copper Rod Continuous Casting / Brass Continuous Casting MachinePowerful Copper Rod Continuous Casting / Brass Continuous Casting MachinePowerful Copper Rod Continuous Casting / Brass Continuous Casting Machine
