    Cooper Smelting Furnace Industrial Copper Melting Furnace , Core Electric Induction Furnace Price

    Ask Lasest Price
    Brand Name : Jingjie
    Model Number : GVT
    Certification : ISO/CE
    Price : negotiation
    Payment Terms : T/T or L/C
    Supply Ability : 20 sets per month
    Delivery Time : 30-45 working days after received your payment
    • Product Details
    • Company Profile

    Cooper Smelting Furnace Industrial Copper Melting Furnace , Core Electric Induction Furnace Price


    Cooper Smelting Furnace Industrial Copper Melting Furnace , Core Electric Induction Furnace Price

    Cooper Smelting Furnace Industrial Copper Melting Furnace , Core Electric Induction Furnace PriceCooper Smelting Furnace Industrial Copper Melting Furnace , Core Electric Induction Furnace PriceCooper Smelting Furnace Industrial Copper Melting Furnace , Core Electric Induction Furnace Price

    1 Melting furnace


    1.1 Main technical parameters
    The work capacity: 2.5 - 3T;
    The highest melting temperature: 1250 degrees centigrade;
    The compensated power factor: 0.95-1.
    The three-phase power supply. The current imbalance: less than 5%.
    The detachable induction body. 600V, 250KW, 50HZ, "W" type spray flu, the inner hole is a rectangular metal
    Ditch, water jacket and coil.
    Oval mouth, electrolytic plate can not cut the whole hanging into the feeding.
    The tilting angle: 92 degrees, which can be emptied of liquid copper furnace, and is convenient for loading and unloading induction body.


    1.2 Characteristics
    1. The quality of domestic production of copper cored induction furnace for furnace construction materials, improve the service life, reduce the temperature of the housing.
    2. Set the auxiliary tools, convenient installation and maintenance of the sensor body.
    3. The "W" type spray flu, is conducive to the molten metal liquid channel directional flow, improve the heat efficiency, reduce
    Temperature difference between the upper and lower parts of the groove, and improve the service life of the induction body.


    2 Holding furnace


    2.1 Main technical parameters
    The work capacity: 3 - 4T;
    The maximum operating temperature: 1250 degrees centigrade;
    Automatic / manual control of liquid temperature;
    Accuracy: + 3.
    The compensated power factor: 0.95-1.
    The three-phase power supply. The current imbalance: less than 5%.
    The detachable induction body. 50HZ, 380V, 180KW.
    Can have melting and heat insulating functions.
    Rearward tilting angle: 92 degrees, replacement and convenient handling induction body is convenient for crystallizer.


    2.2 Characteristics
    1. The quality of domestic production of copper cored induction furnace for furnace construction materials, improve the service life, reduce the temperature of the housing.
    2. Set the auxiliary tools, convenient installation and maintenance of the sensor body.body weight
    Heating temperature: 1200-1300
    Heat preservation temperature: 1150 ~ 1200
    There is class voltage regulation: 100V~600V ten
    Cooling: water cooling
    The cooling water temperature that is not higher than 40 DEG (coil, water jacket, water temperature measuring device)
    Cooling water: 20 ~ 40t/h
    Cooling water pressure: 0.2 ~ 0.4MPa
    Groove type: W type rectangular jet melting groove
